200 Watts FM Transmitter 87.5~108MHz J984086
200 Watts FM Transmitter 87.5~108MHz J984086
Just set the channel you want in the middle of 87.5~108MHz, you can creat your own radio to broadcast sound you want freely. FCC Certified
with just one transmitter you’ll get multiple modes of outputs and easy to tune as per your needs
In the transmitter,DSP&DDS are used to execute all-digital processing,such as digital filtering,pre-emphasis,the generation of pilot frequency.
It can easy broadcast anywhere you want,home,apartment,church, school,club,camping,backyard,resident village.
High performance and very good reliability has been proved by the large usage
Specification
Working Voltage:AC100V-AC260V
Working Current:﹤1A
Frequency Range:87.5~108MHz
Frequency Stability:±10PPM
Frequency Stepping:100KHz
Environment temperature:-10℃~45℃
Output Impedance:50Ω
RF output power:0W~200W
Harmonic, clutter radiation:≤－60dB
Audio distortion:0.5%
Frequency Response:50Hz~15000Hz
Separation:≥35 dB
Input level:≤15 dBV
Frequency Modulation:±75KHZ
SNR:≥65dB
Size:345mm*480mm*45mm
Weight:6KG
Below are the approximate range of different power FM Transmitters. ( The range is diameter )
0.1W ~ 5W FM Transmitter :100M ~1KM
5W ~15W FM Transmitter : 1KM ~ 3KM
15W ~ 80W FM Transmitter : 3KM ~15KM
80W ~500W FM Transmitter : 10KM ~30KM
500W ~1000W FM Transmitter : 30KM ~ 50KM
Package includes：
1*FM Transmitter
1*Audio line
1*Power line
1*English manual
